STP80NF55-06
%5
153,05 TL (Kdv Dahil)
161,10 TL
%3,00
Havale İndirimli Fiyatı : 148,45 TL
29,07 TL den başlayan taksitlerle!!
Stok Kodu
:
674530
STP80NF55-06
Type Designator: STP80NF55-06
Marking Code: P80NF55-06
Type of Transistor: MOSFET
Type of Control Channel: N -Channel
Maximum Power Dissipation (Pd): 300 W
Maximum Drain-Source Voltage |Vds|: 55 V
Maximum Gate-Source Voltage |Vgs|: 20 V
Maximum Gate-Threshold Voltage |Vgs(th)|: 4 V
Maximum Drain Current |Id|: 80 A
Maximum Junction Temperature (Tj): 175 °C
Total Gate Charge (Qg): 142 nC
Rise Time (tr): 155 nS
Drain-Source Capacitance (Cd): 1020 pF
Maximum Drain-Source On-State Resistance (Rds): 0.0065 Ohm
Package: TO220
